The Steam Trap Miyawaki G20N is designed for high-efficiency condensate removal in steam systems, minimizing energy waste and ensuring smooth operation. This durable steam trap is built to withstand demanding industrial environments, providing reliable performance over time.
Why Choose Veža Equipment for Steam Trap Solutions?
At Veža Equipment, we offer durable and efficient steam traps that optimize energy use in steam systems. Our expert team is ready to help you find the best solutions for your industrial applications. With fast shipping and reliable support, Veža Equipment is your trusted partner for steam system components.
| Model | Connection |
Max. operating pressure |
Max. operating differential pressure |
Max. operating temperature |
Body material | ||||
| Type | Size | PMO (MPa) | PMO (psig) | ⊿PMX (MPa) | ⊿PMX (psig) | TMO (℃) | TMO (℉) | ||
| G20N-3 |
Screwed Rc,NPT |
1/2” |
0,3 |
43 | 0,3 | 43 | 220 | 428 |
Ductile cast iron FCD450 |
| 3/4” | |||||||||
| 1” | |||||||||
| G20N-8 | 1/2” | 0,8 | 116 | 0,8 | 116 | ||||
| 3/4” | |||||||||
| 1” | |||||||||
| G20N-21 | 1/2” | 2,1 | 305 | 2,1 | 305 | ||||
| 3/4” | |||||||||
| 1” | |||||||||
| G20N-3F |
Flanged FF,RF |
1/2” | 0,3 | 43 | 0,3 | 43 | |||
| 3/4” | |||||||||
| 1” | |||||||||
| G20N-8F | 1/2” | 0,8 | 116 | 0,8 | 116 | ||||
| 3/4” | |||||||||
| 1” | |||||||||
| G20N-21F | 1/2” | 2,1 | 305 | 2,1 | 305 | ||||
| 3/4” | |||||||||
| 1” |
|
||||||||
●Maximum allowable pressure (PMA): 2,1MPa (305psig) PMA is the pressure that can be tolerated by pressure-resistant parts (body).
●Maximum allowable temperature (TMA): 220℃ (428℉) TMA is the temperature that can be tolerated by pressure-resistant parts (body).
●Minimum operating differential pressure (⊿PMN): 0,01MPa (1.5psig) ⊿PMN is the minimum operating differential pressure between the trap inlet and outlet.
*Available flange standards: ASME/JPI, DIN, JIS
